2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM

Certification
China Bor Hurng Electronic( Zhao Qing) Co., Ltd. certification
China Bor Hurng Electronic( Zhao Qing) Co., Ltd. certification
I'm Online Chat Now

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM
2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM

Large Image :  2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM

Product Details:
Place of Origin: China
Brand Name: TW BOR
Certification: ISO9001 ISO14001 RoHS
Model Number: TRR 1200UF200V 30X50
Payment & Shipping Terms:
Minimum Order Quantity: 1000 pcs
Price: Negotiate
Packaging Details: Carton
Delivery Time: 7 work days
Payment Terms: L/C, T/T
Supply Ability: 1000 million per month

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM

Description
Artical Number: TRR 1200UF200V 30X50 Capacitance: 1200UF
Voltage: 200V Tolerance: ±20%
Application: Switching Power Supplies Supplier Type: Original Manufacture
Type: Aluminum Electrolytic Capacitor Temperature Range: -40 °C +105°C
Material: Aluminum Color: Black
Size: 30X50mm Loade Life: 2000 Hours
ESR (Equivalent Series Resistance): Contact Us To Check Our Datasheet Impedance: Contact Us To Check Our Datasheet
High Light:

Snap In Capacitor 1200UF200V

,

1200UF200V Long Life Capacitor

,

30X50MM Snap In Capacitor



PRODUCT SPECIFICATION



TRR series

Model Number TRR 1200UF200V 30X50
Capacitance Range 47UF~68000UF
Voltage Range 10V~500V
Tolerance ±20%
Temperature Range -40℃~105℃





FEATURES
■105°C,snap-inproductwithterminalseries Wi
de temperature and 2000 hourslong lie

■Explosion-proof structure
■Suited for HID light, UPS and other electronic products



SPECIFICATIONS

Item Key Feature
Operating Temperature Range -40°C~+105°C -25°C~+105°C
Rated Working Voltage Range 10VDC~ 100VDC 160VDC ~ 500VDC
Nominal Capacitance Range 1000uF ~ 68000uF 47uF~ 1000uF
Capacitance Tolerance 土20%(M)(+ 25°C,100/120Hz)
Leakage Current LC≤3,CV,5-minute application of rated working voltage,(+ 25°C)
C: Nominal Capacitance in uF V:Rated Working Voltage in V LC: Leakage Current in uA
Dissipation Factor Rated Working Voltage(V) 10 16 25 35 50 63 100 160 200 250 350 400-500
DF(MAX (+25°C,100/120Hz) 0.50 0.40 0.35 0.35 0.25 0.25 0.20 0.15 0.15 0.15 0.15 0.20
For cpatance of more than 10 add 0.0|2 for every increase of 1000uF
High Temperature Load Life After applying rated working voltage for 2000 hours at 130°C and then being stabilized at+ 25°C,capacitors shall met following limits
Capacitance change Within士20% of the initial measured value
Disipation Factor Less than 300% of the specified value
Leakage Current Withn specified value
High Temperature Shelf Life After storage for 500 hours at 130C With no voltage applied and then being stabilized at+ 25°C,capacitors shall met following limits
Capacitance change Within土20% of the initial measured value
Disspation Factor Less than 300% of the specified value
Leakage Current Less than 300% of the specified value

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 0



Product Details:

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 12000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 22000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 32000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 4



Company Profile:

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 5



BOR HURNG ELECTRONIC (ZHAOQING) CO., LTD



Bor Hurng Electronic Co., Ltd., which was established in Taiwan in 1978, is a professional manufacturer and seller of aluminum electrolytic capacitors. In year 1988, Bor Hurng became one of the first Taiwan enterprises in the circle that invested in China mainland and established its factory in Zhaoqing, Guangdong Province. Land occupation of the factory is 10,000㎡, with the annual capacity of 1.2 billion pieces. And the turnover is over USD$20 million per year. The enterprise is certified by ISO9001:2008 quality management system and ISO14001:2004 environment management system. All products are qualified with RoHS standard approved by SGS.

Bor Hurng’s strongest products are lighting-specialized aluminum electrolytic capacitors with the features of small size, low leakage current, low loss, good consistency, high reliability, wide temperature range and good weldability. The capacitors are suitable for CFL, LED light, HID light, electronic ballast and UPS, etc.. Bor Hurng has an excellent team of R&D experts and workers, with whole sets of fully automatic capacitor production line and testing equipment introduced from Japan and Taiwan. For the above advantages, Bor Hurng enjoys high reputation at home and abroad. Besides China mainland, the products are exported to North America, South America, Europe, Middle Africa, Australia, India, Russia, Singapore as well as other regions and countries. To provide customers with better services, Bor Hurng has set up branch offices in Dongguan, Foshan and Hong Kong.



Capacitor Use:

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 62000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 7



Packing:

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 8





Cooperative Company:

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 9

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 10



Our Certificate

2000 Hours Long Life Snap In Capacitor 1200UF200V 30X50MM 11



WHY CHOOSE US



1.More than 30 years experience for capacitor producing & QC team.

2.Professional R&D and sales team.

3.7day*24 hours on time service.

4.Focus on after service.

5.7day*24 hours on time service.

6.Competitive price.
