Product Details:
|
| Artical Number: | PST33UF400V 16x25 | Capacitance: | 33UF |
|---|---|---|---|
| Voltage: | 400V | Tolerance: | ±20% |
| Operating Temperature: | -40℃~+105℃ | Voltage Range: | 200V~450V |
| Capacitance Range: | 1uF~220uF | Sample Service: | Support |
| Price Term: | FOB | ||
| High Light: | 33UF400V Radial Electrolytic Capacitor,Radial Electrolytic Capacitor 16x25,33UF400V Long Life Capacitor |
||
PST series
FEATURES
■105*C,High ripple current,8000-10000 hours extremely long life.
■Suited for CFL, electronic ballast and other electronic products.
SPECIFICATIONS
| Item | Key Features |
| Operating Temperature Range | -40°C~+105°C |
| Rated Working Voltage Range | 200VDC ~ 450VDC |
| Nominal Capacitance Range | 1uF~ 220uF |
| Capacitance Tolerance | 土20%(M(+ 25°C,100/120Hz) |
| Leakage Current | LC <0.02CV+ 10 uA,2-minute application of ra ted working voltage,(+ 25°C) |
||
| C: Nominal Capacitance in uF | V:Rated Working Voltage in V | LC:Leakage Current in uA | |
| Dissipation Factor | Rated Working Voltage(V) | 200 | 250 | 400 | 450 |
| DF (MAX)(+ 25°C,100/120Hz) | 0.08 | 0.08 | 0.10 | 0.10 |
| High Temperature Load Life | After applying rated working voltage with rated ripple current for 8000 hours at 105°C and test the stabilized capacitors at + 25°C, capacitors shall meet the following limits. | |
| Capacitance change | Within土20 % of the initial measured value | |
| Dissipation Factor | Less than 300 % of the specified value | |
| Leakage Current | Within specified value | |
| High Temperature Shelf Life | After storage for 500 hours at 105 C with no voltage applied and and test the stabilized capacitors at+ 25°C,capacitors shal meet the following limits | |
| Capacitance change | Within土20% of the initial measured value | |
| Dissipation Factor | Less than 200 % of the specified value | |
| Leakage Current | Within specified value | |
Company Profile
BOR HURNG ELECTRONIC (ZHAOQING) CO., LTD
Bor Hurng Electronic Co., Ltd., which was established in Taiwan in 1978, is a professional manufacturer and seller of aluminum electrolytic capacitors. In year 1988, Bor Hurng became one of the first Taiwan enterprises in the circle that invested in China mainland and established its factory in Zhaoqing, Guangdong Province. Land occupation of the factory is 10,000㎡, with the annual capacity of 1.2 billion pieces. We are certified by ISO9001:2008 quality management system and ISO14001:2004 environment management system. All products are qualified with RoHS standard approved by SGS.
Bor Hurng’s strongest products are lighting-specialized aluminum electrolytic capacitors with the features of small size, low leakage current, low loss, good consistency, high reliability, wide temperature range and good weldability. The capacitors are suitable for CFL, LED light, HID light, electronic ballast and UPS, etc.. Besides China mainland, the products are exported to North America, South America, Europe, Middle Africa, Australia, India, Russia, Singapore as well as other regions and countries.
