Product Details:
|
| Model Number: | PST8.2uF400V 10x20 | Capacitance: | 8.2UF |
|---|---|---|---|
| Voltage: | 400V | Tolerance: | ±20% |
| Size: | 18x27mm | Sample Service: | Support |
| Place Of Origin: | Zhao Qing China | Supplier Type: | Original Manufacturer |
| Application: | CFL | ||
| High Light: | 8.2uF 400V LED Light Capacitor,8000 Hours Extremely Long Life Capacitors,LED Light Capacitor 8000 Hours lifetime |
||
PRODUCT SPECIFICATION
PST series
| Model Number | PST8.2uF400V 10x20 |
| Capacitance Range | 1UF~220UF |
| Voltage Range | 200V~450V |
| Tolerance | ±20% |
| Temperature Range | -40℃~+105℃ |
FEATURES
■ 105℃, High ripple current,8000-10000 hours extremely long life.
■ Suited for CFL, electronic ballast and other electronic products.
SPECIFICATIONS
| Item | Key Features |
| Operating Temperature Range | -40°C~+105°C |
| Rated Working Voltage Range | 200VDC ~ 450VDC |
| Nominal Capacitance Range | 1uF~ 220uF |
| Capacitance Tolerance | 土20%(M(+ 25°C,100/120Hz) |
| Leakage Current | LC <0.02CV+ 10 uA,2-minute application of ra ted working voltage,(+ 25°C) |
||
| C: Nominal Capacitance in uF | V:Rated Working Voltage in V | LC:Leakage Current in uA | |
| Dissipation Factor | Rated Working Voltage(V) | 200 | 250 | 400 | 450 |
| DF (MAX)(+ 25°C,100/120Hz) | 0.08 | 0.08 | 0.10 | 0.10 |
| High Temperature Load Life | After applying rated working voltage with rated ripple current for 8000 hours at 105°C and test the stabilized capacitors at + 25°C, capacitors shall meet the following limits. | |
| Capacitance change | Within土20 % of the initial measured value | |
| Dissipation Factor | Less than 300 % of the specified value | |
| Leakage Current | Within specified value | |
| High Temperature Shelf Life | After storage for 500 hours at 105 C with no voltage applied and and test the stabilized capacitors at+ 25°C,capacitors shal meet the following limits | |
| Capacitance change | Within土20% of the initial measured value | |
| Dissipation Factor | Less than 200 % of the specified value | |
| Leakage Current | Within specified value | |
