Product Details:
|
Model Number: | PHR 4.7UF250V 8X12 | Capacitance: | 4.7UF |
---|---|---|---|
Voltage: | 250V | Tolerance: | ±20% |
Lifetime: | 5000 Hours | Operating Temperature: | -40°C ~+105°C |
Supplier Type: | Original Manufacturer, OEM | Advantage 1: | Factory Price |
Advantage 2: | Delivery Fast | Advantage 3: | Samples Offered By Free |
Advantage 4: | 24 Hour On Time Service | Place Of Origin: | Zhao Qing China |
Package: | Normal Carton Packing | Terminal: | Radial |
High Light: | CFL Low ESR Aluminum Electrolytic Capacitors,Aluminum Electrolytic Capacitors 4.7UF250V,Capacitor 4.7UF 250V 8x12MM |
PHR series
■Low impedance at high frequency.
■Ideally suited for use ofswitchingpower supplies andother industrial electronic product applications.
■Loda life of 5000~ 8000 hours at 105°C
SPECIFICATIONS
Key Features
Operating Temperature Range | -40°C~+ 105°C | -40°C~+105°C | -25°C~+ 105°C |
Rated Working Voltage Range | 6.3VDC~ 100VDC | 160VDC- 450VDC | 450-500VDC |
Nominal Capacitance Range | 4.7uF~ 10000uF |
Capacitance Tolerance | +20%(M) (+ 25°C,100/120Hz) |
Leakage Current
LC<0.01CV or 3(uA)which is bigger should be adopted,2 minute application of rated working voltage(+25°C) | LC≤0.02CV+ 10,2 minute application of rated workin g voltage, (+25°C) |
|
Nominal Capacitance in uF | Rated Working Voltage in V | Leakage Current in uA |
Dissipation Factor
RatedWorking Voltage(V) | 6.3 | 10 | 16 | 25 | 35 | 50 | 63 | 100 | 160 | 200 | 250 | 400 | 450-500 |
DFMX(+25°C,100/120HZ) | 0.22 | 0.19 | 0.16 | 0.14 | 0.12 | 0.10 | 0.09 | 0.08 | 0.15 | 0.15 | 0.15 | 0.18 | 0.20 |
High Temperature Load Life
After applying rated working voltage for 5000-8000 hours at 105°C and then being stabilized at + 25°C,capacitors shall meet following limits
Capacitance change | Within土20% of the initial measured value |
Disipation Factor | Less than 300% of the specified value |
Leakage Current | Within specifed value |
High Temperature Shelf Life
Hier sorore for 500 hours at 105°C With no voltage applied and then being sbilill at +25°C, Capacitors shall meet flowing limits
Capacitance change | Within士20% of the initial measured value |
Disspation Factor | Less than 200% of the specified value |
Leakage Current | Less than 200% of the specified value |
Our Certificate
Company Profile
BOR HURNG ELECTRONIC (ZHAOQING) CO., LTD
Bor Hurng Electronic Co., Ltd., which was established in Taiwan in 1978, is a professional manufacturer and seller of aluminum electrolytic capacitors. We are certified by ISO9001:2008 quality management system and ISO14001:2004 environment management system. All products are qualified with RoHS standard approved by SGS.
Bor Hurng’s strongest products are lighting-specialized aluminum electrolytic capacitors with the features of small size, low leakage current, low loss, good consistency, high reliability, wide temperature range and good weldability. The capacitors are suitable for CFL, LED light, HID light, electronic ballast and UPS, etc.. Bor Hurng has an excellent team of R&D experts and workers, with whole sets of fully automatic capacitor production line and testing equipment introduced from Japan and Taiwan. For the above advantages, Bor Hurng enjoys high reputation at home and abroad. Besides China mainland, the products are exported to North America, South America, Europe, Middle Africa, Australia, India, Russia, Singapore as well as other regions and countries.
